1.Products
Product Model:VMC1160
Product Name：Vertical Machining Centre
Standard System：GSK25i Latest System

Product description:
1、X、Y、Z three-axis travel: 1100x600x600mm
2、Spindle rotation mode is belt drive Maximum speed: 8000 rpm.
3、The standard configuration of the tool magazine is 24 tool magazines in disc to meet the needs of customers.
4、Head set is heavy duty box structure, internal rib reinforcement, high rigidity.
5、The spindle is pneumatically operated, so the spindle is uniformly loaded when playing knives, which prolongs the life of the bearings.
6、Electrical box adopts internal isolation design to separate the heat source part of the controller, the front side uses heat exchanger to dissipate the heat to avoid the dust from outside into the box; the back side uses fan to dissipate the heat for the fan heat plate.
7、Three axes adopt high-precision screws of C3 grade, combined with precision nut pre-pressure and end pre-pulling devices to ensure that the backlash and thermal deformation of the machine are kept at a low value for a long time.
8, X, Y, Z axis (X / Z axis for the 6-slider) using H-class roller linear guide, with high rigidity, low noise, can do fast displacement and get the best cycle accuracy.
9、All the finished products have been tested by laser positioning correction and gardening test to ensure the best positioning accuracy and servo characteristics, and the machine has been subject to strict inspection measures before shipment to ensure the long-term stability of the precision of the machine.
