| Technical Parameters of YXLM Series Closed Hydraulic Presses (2024 Edition) |
| No. |
Model |
Unit |
YXLM-100T |
YXLM-160T |
YXLM-200T |
YXLM-250T |
YXLM-315T |
YXLM-400T |
YXLM-500T |
YXLM-630T |
| 1 |
Slider Stroke |
mm |
300 |
300 |
400 |
400 |
500 |
500 |
600 |
600 |
| 2 |
Maximum opening height |
mm |
500 |
500 |
600 |
600 |
800 |
800 |
900 |
900 |
| 3 |
The spacing between the left and right columns |
mm |
868 |
968 |
1060 |
1060 |
1160 |
1168 |
1300 |
|
| 4 |
The height from the worktable to the ground (without the ejector cylinder) |
mm |
680(600) |
680(600) |
700(650) |
950(800) |
1000(850) |
1000(850) |
1000(?) |
|
| 5 |
worktable board |
Left – right × Front – back |
mm |
800×600 |
900×700 |
1000×800 |
1000×800 |
1100×900 |
1100×900 |
1200×1000 |
1300×1000 |
| blanking hole |
mm |
Ф160 |
Ф160 |
Ф160 |
Ф160 |
Ф160 |
Ф160 |
Ф160 |
|
| 6 |
slider |
Left and Right × Front and Back |
mm |
700×500 |
800×600 |
900×700 |
900×700 |
1000×800 |
1000×800 |
1100×900 |
|
| shank hole |
mm |
Ф50 |
Ф50 |
Ф60 |
Ф60 |
Ф60 |
Ф70 |
Diameter 70 / Thickness 100 |
|
| 7 |
Ejector cylinder |
ejecting force |
KN |
250 |
250 |
300 |
500 |
630 |
630 |
630 |
630 |
| ejector stroke |
mm |
100 |
100 |
100 |
200 |
200 |
200 |
200 |
200 |
| 8 |
side opening |
(Dimensions of) Left – Right × Up – Down |
mm |
300×400 |
350×400 |
360×460 |
360×460 |
380×480 |
400×500 |
400×500 |
|
| 9 |
electric machinery |
kw |
11KW |
15KW |
18.5KW |
18.5KW |
22KW |
30KW |
15KWx2 |
22KWx2 |
| 10 |
oil pump |
|
63YCY |
80YCY |
80YCY |
100YCY |
100YCY |
125YCY |
63YCYX2 |
100YCYx2 |
| 11 |
speed |
Fast down |
mm/s |
260 |
290 |
250 |
250 |
250 |
270 |
250 |
270 |
| Working Feed |
mm/s |
16–40 |
12–30 |
10–24 |
10–20 |
8–20 |
8–18 |
6–15 |
8–18 |
| Return Stroke |
mm/s |
230 |
220 |
200 |
210 |
200 |
220 |
190 |
220 |
| 12 |
Overall dimensions of the machine |
Front and Back |
mm |
860 |
920 |
1040 |
1060 |
1180 |
1280 |
1350 |
|
| On the left and right sides of the distribution box |
mm |
1550 |
1785 |
1800 |
1880 |
1980 |
2000 |
2200 |
|
| Up and down (including the fuel tank) |
mm |
3200 |
3350 |
3500 |
3850 |
4250 |
4300 |
4480(?) |
|
| 13 |
Required fuel tank volume |
L |
548/610 |
696/800 |
696/800 |
870/980 |
870/980 |
1087/1300 |
1461/1500 |
|
| 14 |
Weight (Frame + Slide Block + Hydraulic Cylinder) |
T |
≈4.5 |
≈5.5 |
~7 |
≈8.5 |
≈11 |
~13.5 |
≈17 |
|
|
Foundation Plan: Left and Right × Front and Back |
1066×760 |
1216×810 |
1275×920 |
1325×930 |
1425×1040 |
1440×1140 |
1590×1210 |
1590×1210 |
| Foundation Plan: Left and Right × Front and Back (Without Jacking Cylinder) |
1066×760 |
1216×810 |
1270×920 |
1320×930 |
1425×1040 |
1440×1140 |
|
|
